Device specifications:

Packaging items: confectionary cream, curd, pasteurized milk, buttermilk, edible oil, drinking water
Packaging capacity: 500 5 liter packages per hour
Packable volumes: one and a half liters to five liters
Sewing jaws system: pneumatic
Machine control system: by PLC
Ability to connect to CIP washing unit
Stainless steel chassis, switchboard cabinet and liquid passageway
Equipment:

Disinfection of polyethylene rolls by UV rays
Electronic eye to adjust the logo
The date of the thermal woman to insert the date of production and expiration
Frequency inverter to adjust the amount of liquid to be packed
Warning system for finishing the polyethylene roll and stopping the operation of the machine
The warning system for the end of the thermal history ribbon and stopping the device from continuing to work
Primary pre-heating unit for sewing jaws to remove the primary waste of polyethylene rolls
Changing the parameters of the device through the touch screen


Technical Specifications:

Device dimensions: 125 x 100 x 300 cm (length x width x height)
Machine weight: about 500 kg
Power consumption of the device: 2 kilowatts per hour
Compressed air consumption: 80 liters per minute (6 times pressure)
Water consumption for sewing jaws cooling: 100 liters per hour (15-20 degrees)
Specifications of the consumable roll:

Three layers of polyethylene and one layer of LDPE
The thickness of the used roll: 90-110 micrometers
The width of the used roll: 60 cm
The diameter of the used roll: maximum 20 cm
Weight of a five-liter bag: 20 grams
