FuelGas / Light Oil / Heavy Oil
P.O.C. VelocityMedium Velocity
Turn-down Ratio6:1 for Gas / 3:1 for Oil
Capacity870,000 to 7,500,000 kCal/hr
ApplicationsPre-Heat Furnaces, Melting, Hot Gas Generators up to 1450°C
RemarksThese burners can be ordered as single fuel or dual fuel.

Extra Information

Medium-velocity burners are the burners that the POC (products of combustion) velocity from the burner exit peaks at 40 m/s. These burners are usually used in melting, steel preheating and hot gas generators. Although usage of these burners is widespread, care should be taken while setting combustion parameters. One of the drawbacks is starting them with air pressure less than design pressure. This leads to POC velocity reduction converting the burner to a low-velocity type. Sometimes they are used instead of high-velocity burners, that eventually leads to non-uniform heating. These burners are presented in single and dual fuel mode. Also, the burner head is resistant to high temperatures.

MGHO
870MGHO    870,000 kCal/hr
1500MGHO    1,500,000 kCal/hr
2500MGHO    2,500,000 kCal/hr
4500MGHO    4,500,000 kCal/hr
7500MGHO    7,500,000 kCal/hr
